VAP-X™ 3 STREAM
Vap-X™ 3 Phase has been formulated to greatly reduce H2S and CO2 in an oil, water, and gas system. It effectively reduces all three streams by 50-70% of its H2S and CO2. The product adjusts the pH of the water from the acidic phase to a neutral pH once the reaction is complete.
WHY VAP-X™ 3 STREAM
The product adjusts the pH of the water from the acidic phase to a neutral pH once the reaction is complete. Vap-X™ 3 Phase is engineered with a higher RVP allowing the treatment of the gas phase via gas partitioning. The chemical is applied utilizing a static mixer via a commingled stream (oil, has, and water) allowing for turbulent mixing between the three phases.
A critical aspect of the treatment is the mixing energy to make sure all the molecules have contact with the solution. With very minimal capital expenditure this product will show how it can impact a field. Bring shut-in production back online with ability to treat previously thought to be uneconomical wells to produce. Vap-X™ 3 Phase is best utilized in high H2S concentrations with consistent liquid flow.
The dosing rate is based on volume of liquid flow rate and water volume where pH is controlled to help mitigate fallout from occurring. Vap-X™ 3 Phase also has a proprietary chemical additive that acts as a corrosion inhibitor.
SOLUTIONS
Application
- Apply dosage mainly based on volume
- Treat inline before separation
- Mitigate 1,000s of lbs of Sulfur via chemical injection
- Contaminants stay suspended not allowing for fallout
Benefits
- Requires lower dosage
- No supply chain issues
- More economical than other options
- Non-Triazine base
Physical Data
- Colorless
- 1.2 Specific Gravity
How It Works
1. Comingled Stream
Treated via comingled oil/gas/water stream. Added consistent stream of water.
2. Pilot Program
Treated oil/water/gas 90,000ppm - Gas Phase H2S
3. Mitigation
H2S down to 8,000ppm (91% reduction)
4. Take a Load Off Ultra-Fab
Greatly reduce the sulfur load on current ultra-fab applications
5. Economics
325 MCF, 110 bbl/oil, and 160 bbl water
✓ Targets All Sulfide (including Iron sulfide)
✓ Low Dosage for High PPM
✓ Stream Dependent
